Philips ICN2S40N Electronic Electronic Ballast, 120 - 277 VAC, 0.26 - 0.62 A, Rapid Start, 0.85 - 0.95 Ballast, 2 40 W

Advance, Centium

Philips ICN2S40N Electronic Electronic Ballast, 120 - 277 VAC, 0.26 - 0.62 A, Rapid Start, 0.85 - 0.95 Ballast, 2 40 W

$35.99$35.99
Philips ICN2S40N Electronic Electronic Ballast, 120 - 277 VAC, 0.26 - 0.62 A, Rapid Start, 0.85 - 0.95 Ballast, 2 40 W
  • Amperage Rating: 0.26 - 0.62 A
  • Ballast Factor: 0.85 - 0.95
  • Enclosure Type: NEMA 410
  • Finish: White Painted
  • Frequency Rating: 50/60 Hz
  • Model #: ICN2S40N
  • UPC #: 781087074879
  • SKU: 0044024

Your shopping list will be used for pickup in-store

Product Details

Advance Centium Lamp Ballast, Electronic, Series: ICN-2S40-N35M, 120/277 V, 72 W, 0.62 - 0.26 A, 50/60 Hz, Fluorescent Lamp, T12 Lamp Base, 40 W Lamp, 2 Lamps, 0.85, Rapid Start, >0.9, 10 - 50 deg F Minimum, NEMA 410 Enclosure, 25 deg F, 1 in Overall Height, 1.3 in Overall Width, 9-1/2 in Overall Length, Aluminum, White Painted, Maximum THD <10%

Key Features

  • 20 - 24 db noise level
  • High power factor
  • Series lamp wiring

Item Specifications

Amperage Rating0.26 - 0.62 A
Ballast Factor0.85 - 0.95
Enclosure TypeNEMA 410
FinishWhite Painted
Frequency Rating50/60 Hz
Includes36 in Violet and Gray Control Leads
Lamp Base TypeT12
Lamp TypeF40T12 Fluorescent, T12
Lamp Wattage40 W
Lighting TechnologySeries
MaterialMetal
Minimum Starting Temperature50 deg F
Number of Lamps2
Overall Height1 in
Overall Length9-1/2 in
Overall Width1.31 in
Power Factor0.98
SeriesAdvance, Centium
Special Features18 AWG Solid Wire
StandardsCE Certified, CSA Certified, UL Listed, RoHS Compliant
Start TypeRapid
Temperature Range70 deg C
TypeElectronic
UsageFor Outdoor Applications
Voltage Rating120 - 277 VAC
Wattage72
